MA-5002VZ Service Manual130446-1 Rev A
Exploded View Parts 7-19
©2000 Crown International, Inc.
7.9 PIP Terminator Shelf Assembly
NotesItem # QTY Part Number Description
1 3 A10086-10604 6-32-.25 Machine Screw Phillips, round-head
2 3 A10094-4 #6 Int. Star Washer
3 1 --- Current Sense Module See Section 8
4 1 C 7705-4 Cable Clamp
5 1 --- Current Sense Module See Section 8
6 3 C 8823-4 0.125” PC Board Support
7 2 D 5903-6 8-32x.5 Screw Phillips, flat-head, taptite
8 1 F11160-3 Strain Relief For Power Cord D 7890-3
9 1 D 7890-3 Power Cord 30A 10/3 TT-30P Plug (No. America)
10 1 A10111-10806 #8x.375 Sheetmetal Screw Pan-head
11 1 A10095-2 #8 Ext. Star Washer
12 1 D 7817-6 Center Output Slide Guide
13 1 A10109-7064 6-20x.25 Screw Phillips, pan-head, black
14 1 F12699-9 Terminator/PIP Shelf Bracket
15 1 H43430-0 Output Flex Bar Ch 1 Includes Insulating Sleeve
1 H43431-8 Output Flex Bar Ch 2 Includes Insulating Sleeve
16 1 --- Line Filter PWA See Section 8 (Export Only)
