MA-5002VZ Service Manual130446-1 Rev A
Exploded View Parts 7-23
©2000 Crown International, Inc.
7.12 Output Assembly
(Channels 1 & 2 Identical)
NotesItem # QTY Part Number Description
1 8 C 8187-4 NPN Outputs,
8 C 8188-2 PNP Outputs,
2 1 F12154-5 Heatsink
3 1 M21188-4 Flex Bar Fastener
4 1 --- Negative Emitter Module See Section 8.
5 1 --- Negative Output Module See Section 8.
6 1 D 7922-4 Insulator
7 4 A10224-9 Rubber Grommets
8 1 --- Positive Output Module See Section 8.
9 2 C 8789-7 Flex Bar Spacers
10 1 --- Positive Emitter Module See Section 8.
11 2 D 7870-5 Valox Washer
12 3 A10100-16 Washer, 7/16OD X ,203ID
13 2 A10098-4 Belleville Washer, #10
14 2 A10086-10810 Screw, 8-32 X .62
15 3 A10094-6 Lock Washer, #8 Int. Star
16 1 A10089-10612 Screw, 6-32 X .75
17 32 A10110-10606 Screw, 6-32 X .375
18 1 A10089-10808 Screw, 8-32 X .5
19 1 A10089-70820 Screw, 8-32 X 1.25
20 4 A10086-10406 Screw, 4-40 X .37
21 4 A10098-1 Washer, .394OD X .126ID
22 6 A10086-10604 Screw, 6-32 X .25
23 4 A10094-4 Washer, #6 Int Star
24 4 C 6541-4 Predriver Torque Spreader
25 2 C 5453A1 PNP, 2SA1006BR
2 C 6436-7 NPN, 2SC2336BR
26 2 C10223-3 PNP, MJL1302A
2 C10224-1 NPN, MJL3281A
27 1 D 7871-3 Valox Spacer
