MA-5002VZ Service Manual130446-1 Rev A
Exploded View Parts 7-27
©2000 Crown International, Inc.
Interconnect Cables
J2A D 9236-7 20 Wire Ribbon Cable PIP2
J2B D 9235-9 18 Wire Ribbon Cable PIP2
J35 D 7886-1 16 Wire Ribbon Cable Main to Control to Display
J500 D 7889-5 16 Wire Ribbon Cable Main to Ch 1 Output P500 (top)
J501 D 7885-3 16 Wire Ribbon Cable Main to Ch 1 Output P501 (bottom)
J600 D 7885-3 16 Wire Ribbon Cable Main to Ch 2 Output P500 (bottom)
J601 D 7964-6 16 Wire Ribbon Cable Main to Ch 2 Output P501 (top)
J700 D 7887-9 16 Wire Ribbon Cable Main to Current Sense
J732 J832 D 7888-7 16 Wire Ribbon Cable Main to Control
D 8542-9 16 Wire Ribbon Cable Main to Control, Part of Control Mod.
J733 J833 H43479-7 Bi-Level Control Wires Control to Bi-Level Switches
R120 R220 H43551-3 Level Controls With Wires Also includes hardware
NotesDesignation Part Number Description
