CS Instruments FA 550 User Manual

Operation
Page 28 FA 550 V1.00
12.3.4.1.2 Network Settings static IP
Settings  Network Setup Settings  IP Address  IP Address
Settings  Network Setup Settings  IP Address  Sub Netz
Settings  Network Setup Settings  IP Address  Gateway
For manual (static) IP, the "IP Address",
"Subnet" and "Gateway" selection keys must
be selected and activated with "OK".
The first data field of the selection, in this case
the IP address, is then marked (red).
Confirm with "OK” the corresponding input
menu is opened.
By means of ">", the next data field is
changed.
Select the desired position with the ">" key
and activate it with the "OK" key.
Change the values with the ">" key, and
accept the values with the "OK" key.
Procedure for "Subnet" and "Gateway" is
analogous.
Store the settings by „Save“
