CS Instruments FA 550 User Manual

Operation
Page 29 FA 550 V1.00
12.3.4.1.3 Modbus TCP Settings
Settings  Network Setup Settings  IP Address  MB TCP
Settings  Network Setup Settings  IP Address  ID
Settings  Network Setup Settings  IP Address  Port
For changes, e.g. the sensor ID,
first select by pressing key „>“ the field “ID”
and then key “OK”.
Select the desired position by pressing the ">"
and select with "OK" button.
Change values by pressing the „>“ values
takeover by pressing "OK".
Input for the port is done analogue.
By means of the button "Byte Format" it is
possible to change the data format (Word
Order). Possible formats are "ABCD" (Little
Endian) and "CDAB" (Middle Endian)
Saving the changes by pressing "Save",
therefore select it with key „>“ and then
confirm it with "OK".
Reset to the default settings by activating "Set
to Default"-
