Measuring ranges
VX 570 English V1.10 Seite 12 von 44
Measuring range for steam VX 570 under operating conditions in kg/h
Pipe Inner diameter
T=410 °F
T=419 °F
P=261 psi(g)
P=290 psi(g)
D=0.5989 lb/ft3
D=0.6599 lb/ft3
Inch
mm
Min
Max
Min
Min
Max
1/2″
15
DN 15
80.7
940.9
88.9
1036.8
3/4″
20
DN 20
143.4
1672.8
158.0
1843.2
1″
25
DN 25
149.4
2613.7
164.6
2879.9
1 1/4″
32
DN 32
244.7
4282.4
269.6
4718.5
1 1/2″
40
DN 40
191.2
6691.2
210.6
7372.7
2″
50
DN 50
298.7
10455.0
329.1
11519.8
2 1/2″
65
DN 65
504.8
17668.9
556.2
19468.4
3″
80
DN 80
764.7
26764.8
842.6
29490.6
4″
100
DN 100
1194.9
41819.9
1316.5
46079.1
5″
125
DN 125
1867.0
65343.7
2057.1
71998.6
6″
150
DN 150
2688.4
94094.9
2962.2
103678.0
8″
200
DN 200
4779.4
167279.8
5266.2
184316.4
10″
250
DN 250
7467.8
261374.7
8228.4
287994.4
12″
300
DN 300
10753.7
376379.5
11848.9
414711.9
