11.3.1.4 Extended Sensor Settings
11.3.1.4.1 Definition of the reference settings
Here can be defined the desired measured media reference conditions for pressure,
temperature and times for the filter and averaging.
Setup → Sensor Setup→ Advanced
Remark:
• Factory pre-setting for reference temperature and reference pressure are 20 °C, 1000
hPa
• All volume flow values (m³/h) and consumption values indicated in the display are
related to 20 °C and 1000 hPa (according to ISO 1217 intake condition)
• Alternatively 0 °C and 1013 hPa (=standard cubic meter) can also be entered as a
reference.
• Do not enter the operation pressure or the operation temperature under reference
conditions!
Setup → Sensor Setup→ Advanced → Ref. Settings
To make changes, first select a menu item with
the „>“ key and then select it with the „OK key.
With „set to Default“ the reference conditions
are set back to 1000mbar / 20°C.
