Page #35 background image
Operation
VX 570 English V1.10 Seite 35 von 44
11.3.2.2 Modbus Settings (2001…2005)
Modbus
Register
Register
Adresse
No.of
Byte
Data
Type
Description
Default
Setting
Read
Write
Unit /Comment
2001
2000
2
UInt16
Modbus ID
1
R/W
Modbus ID 1…247
2002
2001
2
UInt16
Baudrate
4
R/W
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 38400
2003
2002
2
UInt16
Parity
1
R/W
0 = none
1 = even
2 = odd
2004
2003
2
UInt16
Number of Stopbits
R/W
0 = 1 Stop Bit
1 = 2 Stop Bit
2005
2004
2
UInt16
Word Order
0xABCD
R/W
0xABCD = Big Endian
0xCDAB = Middle Endian
11.3.2.3 Values Register (1001 …1500)
Modbus
Register
Register
Adresse
No.of
Byte
Data Type
Description
Def
ault
Read
Write
Unit /Comment
1101
1100
4
Float
Flow in m³/h
R
1109
1108
4
Float
Flow in Nm³/h
R
1117
1116
4
Float
Flow in m³/min
R
1125
1124
4
Float
Flow in Nm³/min
R
1133
1132
4
Float
Flow in ltr/h
R
1141
1140
4
Float
Flow in Nltr/h
R
1149
1148
4
Float
Flow in ltr/min
R
1157
1156
4
Float
Flow in Nltr/min
R
1165
1164
4
Float
Flow in ltr/s
R
1173
1172
4
Float
Flow in Nltr/s
R
1181
1180
4
Float
Flow in cfm
R
1189
1188
4
Float
Flow in Ncfm
R
1197
1196
4
Float
Flow in kg/h
R
1205
1204
4
Float
Flow in kg/min
R
1213
1212
4
Float
Flow in kg/s
R
1221
1220
4
Float
Flow in kW
R
