Operation
VX 570 English V1.10 Seite 29 von 44
11.3.1.2 Input / change consumption counter
Setup Sensor Setup Total Counter
Unit button
Important!
When the counter reach 100000000 m³ the counter will be reset to zero.
11.3.1.3 Definition of the units for flow, velocity, temperature and pressure
Setup Sensor Setup Units
In order to change, e.g. the unit, first select by
pressing key > the button Unit” and then key
OK”.
Select with the key > the correct unit and then
confirm selection by pressing 2x OK“.
Entering / changing the consumption counter
via button >, select the respective position and
activate the position with the "OK" button.
By pressing > the position value is incremented
by 1. Complete with "OK" and activate next
number position.
Confirm entry by pressing „OK“.
To make changes to the unit for the respective
measurement value, first select by pressing > the
field of the „measurement value“ and activate „it
with „OK“ .
Selection of the new unit with >
In case the quantity of units selectable are not
presentable on one page, pleas move to next page
by pressing „<<“.
Confirm selection by pressing 2x „OK“.
Procedure for all 4 measurement-variables is
analogous.
