CS Instruments Vortex VX 570 User Manual

Dimension
VX 570 English V1.10 Page 16 of 44
9 Dimension
9.1 Zwischenflansch-Ausführung
Intermediate (wafer) Version
Pipe
[DN]
ØD
[mm]
ØK
[mm]
L
[mm]
Height H
150℃
250℃
350℃
15
15
75
65
294
335
475
20
20
75
65
294
335
475
25
25
75
65
289
330
470
32
32
80
65
293
334
474
40
40
84
65
296
337
477
50
50
94
65
301
342
482
65
65
105
65
309
350
490
80
80
120
65
316
357
497
100
100
140
90
327
368
508
125
125
165
65
341
382
522
150
150
190
65
353
534
534
200
200
240
85
378
559
559
250
250
290
100
404
585
585
300
300
340
120
429
609
609
