Measuring ranges
VX 570 English V1.10 Seite 9 von 44
Measuring range for steam VX 570 under operating conditions in kg/h
Pipe Inner diameter
T=112 °C
T=121 °C
T=134 °C
T=144 °C
P=0.5 bar(g)
P=1 bar(g)
P=2 bar(g)
P=3 bar(g)
D=0.8798 kg/m3
D=1.155 kg/m3
D=1.672 kg/m3
D=2.185 kg/m3
Inch
mm
DN
Min
Max
Min
Max
Min
Max
Min
Max
1/2″
15
DN 15
3.4
39.1
4.4
51.4
6.4
74.4
8.3
97.2
3/4″
20
DN 20
6.0
69.6
7.8
91.4
11.3
132.2
14.8
172.8
1″
25
DN 25
6.2
108.7
8.2
142.7
11.8
206.6
15.4
270.0
1 1/4″
32
DN 32
10.2
178.1
13.4
233.9
19.3
338.6
25.3
442.4
1 1/2″
40
DN 40
8.0
278.4
10.4
365.4
15.1
529.0
19.8
691.3
2″
50
DN 50
12.4
434.9
16.3
571.0
23.6
826.6
30.9
1080.2
2 1/2″
65
DN 65
21.0
735.0
27.6
964.9
39.9
1396.9
52.2
1825.5
3″
80
DN 80
31.8
1113.4
41.8
1461.7
60.5
2116.0
79.0
2765.2
4″
100
DN 100
49.7
1739.7
65.3
2283.9
94.5
3306.2
123.4
4320.6
5″
125
DN 125
77.7
2718.3
102.0
3568.6
147.6
5166.0
192.9
6751.0
6″
150
DN 150
111.8
3914.4
146.8
5138.8
212.5
7439.0
277.8
9721.4
8″
200
DN 200
198.8
6958.9
261.0
9135.6
377.9
13224.9
493.8
17282.5
10″
250
DN 250
310.7
10873.2
407.8
14274.4
590.4
20663.8
771.5
27003.9
12″
300
DN 300
447.4
15657.5
587.3
20555.1
850.2
29755.9
1111.0
38885.6
Measuring range for steam VX 570 under operating conditions in kg/h
Pipe Inner diameter
T=159 °C
T=165 °C
T=171 °C
T=176 °C
P=5 bar(g)
P=6 bar(g)
P=7 bar(g)
P=8 bar(g)
D=3.182 kg/m3
D=3.671 kg/m3
D=4.218 kg/m3
D=4.723 kg/m3
Inch
mm
DN
Min
Max
Min
Max
Min
Max
Min
Max
1/2″
15
DN 15
12.1
141.6
14.0
163.3
16.1
187.7
18.0
210.1
3/4″
20
DN 20
21.6
251.7
24.9
290.4
28.6
333.6
32.0
373.6
1″
25
DN 25
22.5
393.3
25.9
453.7
29.8
521.3
33.4
583.7
1 1/4″
32
DN 32
36.8
644.3
42.5
743.3
48.8
854.1
54.6
956.3
1 1/2″
40
DN 40
28.8
1006.7
33.2
1161.4
38.1
1334.5
42.7
1494.3
2″
50
DN 50
44.9
1573.0
51.9
1814.8
59.6
2085.2
66.7
2334.8
2 1/2″
65
DN 65
76.0
2658.4
87.6
3066.9
100.7
3523.9
112.7
3945.8
3″
80
DN 80
115.1
4026.9
132.7
4645.8
152.5
5338.0
170.8
5977.1
4″
100
DN 100
179.8
6292.1
207.4
7259.0
238.3
8340.7
266.8
9339.3
5″
125
DN 125
280.9
9831.4
324.1
11342.2
372.4
13032.3
416.9
14592.6
6″
150
DN 150
404.5
14157.2
466.7
16332.8
536.2
18766.5
600.4
21013.3
8″
200
DN 200
719.1
25168.4
829.6
29036.2
953.2
33362.7
1067.3
37357.1
10″
250
DN 250
1123.6
39325.6
1296.3
45369.0
1489.4
52129.2
1667.7
58370.4
12″
300
DN 300
1618.0
56628.8
1866.6
65331.4
2144.7
75066.1
2401.5
84053.4
