Chapter 3. LCD Operation
27
May 2011
To enable the remote mapping function on this unit, from the SEND MAPPING sub-menu
press the Right Arrow key to the REMOTE MAPPING screen.
< R E M OTE MAPPING >
C O N TROLLED:ON
When ON, this unit will allow "Remote Mapping Control" from the remote connected unit. If
OFF, the remote unit may not modify this unit's timeslot mapping. To modify the parameter, press
ENTER once, then use the arrow keys to toggle "ON" or "OFF". Press ENTER to effect the change.
Typical settings would place the CO side unit to controlled "OFF", while the CPE side device
would be controlled "ON".
Note: This is a proprietary function which uses the reserved SA bits of FAS header to perform
an in-band management. This function will not work if E1 framing is set to Unframed. It will
also only work when connected to another ETU-01A or to ERM01 E1 concentrator.
From the REMOTE CONFIG sub-menu press ESC to return to the SYSTEM PARAMETER
screen. Press the Right Arrow key to the MODIFY PASSWORD screen.
< M O D I F Y >
P A SSWORD
Press ENTER;
M o d ify Passwor d
I n p ut PWD:0___
Use the arrow keys to change each value, 0~9 and then press ENTER to edit the next value.
Any password can be entered from 0000~9999. It must be entered twice to check that password was
properly keyed. Use the value 0000 to clear any previous password, i.e. 0000 equals no password.
Contact your distributor or agent if you set and forget the password and need to recover the unit.
3.4.3 E1 Line Parameter Detail
The following screens show the setup screens under the E1 Line Parameter Screen.
< E 1 LINE >
P A RAMETER
