Chapter 3. LCD Operation
30
May 2011
Use the arrow key to move on to the next parameter setting for CTS.
< D A T A P O R T >
C T S : O N
Press ENTER to move the cursors to the CTS field. Select either ON or RTS using the arrow
keys, then press ENTER to effect the change. The default setting is ON.
Note:
CTS ON means the CTS signal will always be pulled high. When set to RTS, it means the CTS
signal will "follow" RTS.
If the Data Port channel module is not installed, a readout similar to the following will be displayed.
N C RECO N64
256Kbps
3.4.6 Loop back Parameter Detail
The following shows the setup screens under the Loop back Parameter Screen.
LOOPBACK PARAMETER.
< L O O P B A C K >
P A R A M E T E R
Press ENTER
< E 1 L I N E >
L O O P B A C K O F F
Use the arrow keys to select between the E1 LINE or DATA PORT loop back settings. The
DATA PORT display is as follows:
< D A T A P O R T >
L O O P B A C K O F F
Use the arrow keys to browse the available options for both the E1 Line Loop back and the
Data Port Loop back settings. The details for both are as follows:
E1 Line; Loop back Off, Local Analog, Local Digital, Local Payload, Remote Analog or
Remote Payload. Default is Loop back Off.
Data Port; Loop back Off, Local Analog, Local Digital, or V.54 Loop. Default is Loop back
Off.
Press ESC twice to back out to LOOP BACK PARAMETER and use the right arrow key to
move on to the BERT TEST menu.
