CTC Union ETU-01A User Manual

Chapter 6. SNMP Option
71
May 2011
Text 5:
Alarm Buffer trap code:
Code Error message Error status On/Off
0 Alarm Buffer Empty 0:None
1 Power Turn 1:On 2:Off
2 Main Link Signal Loss 1:On 2:Off
3 Main Link SYNC Loss 1:On 2:Off
4 Main Link AIS 1:On 2:Off
5 Main Link RAI 1:On 2:Off
6 Main Link MRAI 1:On 2:Off
7 Main Link BPV 0:None
8 Main Link Frame Slip 0:None
9 Main Link CRC4 Error 0:None
10 Sub Link Signal Loss 1:On 2:Off
11 Sub Link SYNC Loss 1:On 2:Off
12 Sub Link AIS 1:On 2:Off
13 Sub Link RAI 1:On 2:Off
14 Sub Link MRAI 1:On 2:Off
15 Sub Link BPV 0:None
16 Sub Link Frame Slip 0:None
17 Sub Link CRC4 Error 0:None
18 Channel 1 port FIFO Slip 0:None
19 Channel 2 port FIFO Slip 0:None
20 Channel 3 port FIFO Slip 0:None
21 Channel 4 port FIFO Slip 0:None
22 Channel 1 port Baud Rate
Failure
0:None
23 Channel 2 port Baud Rate
Failure
0:None
24 Channel 3 port Baud Rate
Failure
0:None
25 Channel 4 port Baud Rate
Failure
0:None
26 End of Alarm Buffer 0:None
Alarm message Transfer format:
Text 1 (9) Text 2 (10) Text 3 (11) Text 4 (12) Text 5 (13) Text 6 (14) Text 7 (15) Text 8 (16)
Message
Type Code
On/Off Code Year (BCD) Month
(BCD)
Date (BCD) Hour (BCD) Minute
(BCD)
Second
(BCD)
Text 6:
LED Status:
Parameter
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Test Error Sub Alarm Sub SYNC
Loss
Sub Signal
Loss
Main Alarm Main SYNC
Loss
Main Signal
Loss
