Cube EPO pedelec User Manual

27
A
Be aware of possible grease or assembly paste residues
on the seat post of your CUBE EPO pedelec. Make sure not
to soil yourself and your clothes, when removing the re-
chargeable battery.
A
When you remove your seat post battery for charging it
from the seat post with your CUBE EPO pedelec left in the
open during the charging process, you shold protect the
seat tube e.g. with a plastic bag against rain, water, mois-
ture and dirt.
Mounting the Rechargeable Battery
Take the cable that runs inside the seat tube and connect the mag-
netic connection with the socket at the bottom end of the seat post
battery.
Subsequently, insert the seat post carefully into the seat tube of your
CUBE EPO pedelec. Determine the height of your seat post according
to your needs with the marking on the seat post rear
(h) . For more
information see chapter
“Adjust saddle height” of your general
CUBE handbook.
f he g
Tighten the Pinhead®-locking system at the seat post of your CUBE
EPO pedelec.
Connect the magnetic connector to the charging socket of the re-
chargeable battery at the bottom bracket.
g
Do not pull out the seat post too far. The mark on the seat
post (Min. insert) should always remain within the seat
tube.
A
Make sure the plug contacts remain undamaged, clean
and dry while the battery is removed.
