EQUIPMENT OVERVIEW
The MPlus XL System consists of the following equipment. Refer to the BOM and Exploded View
Drawings at the back of this manual for additional information.
MPLUS+ XL LARGE CONFIGURATION SYSTEM
(CH) Control Unit with Text Writing, Observation Coding, Digital Recording and Industrial Grade Monitor
in an Injection Molded Enclosure:
• The MPlus XL system is controlled by the PCU (power control unit). The PCU contains all of the controls
for the system including system power, camera, P/T camera, lighting, recording, video titling, and observation
coding. The CH Control Unit is compatible with the standard and XL congurations. The following functions
are included:
• .” industrial grade, optically bonded, sunlight viewable, monitor with anti-reective properties and LED backlighting
• Operator Interface with controls for all camera functions including:
o Pan right and pan left
o Rotate clockwise and rotate counter-clockwise
o Focus near (-) and focus far ()
o Home, Automatic picture leveling
• Video Titling includes multiple predened and customizable screens
• Digital video recording features recording and playback of video and screenshot picture images; Includes
an internal USB ash drive with GB storage and an external USB ash drive with GB storage for copying
videos and photos
• Control Unit quick bracket mount for attaching to the coiler with hands free locking
• System Interface connector features Video, Audio, distance counter quadrature and VDC outputs and a
Video input
• Built-in Li-Ion Battery with advanced charging technology for hours of continuous use
• Universal AC power input - volt AC, / Hz, or volt DC power source
• Operation & Maintenance User Manual
(CH) Stainless Steel Coiler:
• The coiler assembly stores up to feet of .” berglass push rod and is equipped with ” wheels for easy
portability.
• Heavy gauge and corrosion-resistant Stainless Steel construction
• Large ” durable wheels for portability and a balanced footprint for stability
• Quick-Connect allows Control Unit mounting with axes adjustability
• Adjustable coiler brake
• Integral distance sensor
(CH-PE) ’ of .” Push Cable (.” berglass rod) and HDPE Jacket Push Cable:
• The push cable transmits power to the self-leveling color camera or PT camera head and also carries the video
signal back to the PCU.
• Push Cable with durable HDPE jacket and advanced berglass rod
• Features a disconnect termination for Camera Head interchangeability
(SR SERIES) Self-Leveling Color Camera:
• The mini-camera provides live video during sewer pipe inspections. It attaches to the push cable by utilizing a
exible leader spring (CH) with a disconnect termination.
• ½” diameter Stainless Steel camera head designed for ” to ” pipelines
• Hz integral sonde
• high intensity LED’s
(CH KIT - CONTAINS LL SERIES) P/T Camera:
• The Pan and Tilt camera provides live video during sewer pipe inspections. It attaches to the push cable by
utilizing a exible leader spring (CH) with a disconnect termination.
• ½” diameter Stainless Steel and anodized aluminum alloy camera head designed for ” to ” pipelines
• Variable focus, xed iris and auto speed shutter
• Lens wiper
• /” Interline Transfer CCD with a pixel resolution of (H) x (V)
• Hz and kHz integral sonde
• Spot and Flood LED’s
