 CUES Inc., MPlus+ User Manual | CH905
www.cuesinc.com, | salesinfo@cuesinc.com
SET-UP & INSTALLATION
CONFIGURING THE COILER AND PUSH CABLE
Note: The following conguration procedure must be followed after all system related
service, push cable service and/or retermination, push cable replacement or if coiler is
being interchanged
Enter “Coiler Setup” in the System Menu and conrm or congure PUSH ROD
LENGTH, COILER TYPE and COUNT DIRECTION.
• PUSH ROD / CABLE LENGTH
• XXX.X - NOTE: enter actual length to one decimal place using the Up Arrow and
Down Arrow keys to modify the value in the eld displayed. Use the Left Arrow and
Right Arrow keys to move within the eld. The value is changed upon exiting from
the eld by pressing ENTER or ESC.
• Prior to changing the push rod or cable’s length, all of the cable must be inside the
basket/coiler because the rmware assumes this is the case when computing the
footage distance.
COILER SETUP
COILER TYPE
PUSH ROD / CABLE LENGTH
AUX. REEL SCALING COUNT
COUNT DIRECTION
COILER SETUP
COILER TYPE
WARNING: ALL CABLE MUST
BE IN BEFORE PROCEEDING!
STANDARD BASKET
XL BASKET
AUXILIARY REEL
COILER TYPE
