OPERATING THE SYSTEM
SYSTEM STATUS
CAMERA: XX.X V Y.YY A
LIGHTS: XX.X V Y.YY A
+12V: XX.X V Y.YY A
BATT: XX.X V Y.YY A
KYBD: POWER OK
TEMP.: ZZZ C
SYSTEM STATUS
The SYSTEM STATUS screen displays the voltage and amperage readings of the camera,
lights, V, battery, and keyboard for diagnostics purposes. Voltage is given with one
decimal place whereas amperage is given with two decimal places. It also displays the
temperature of the battery in whatever units system is chosen (shown here in Celsius).
