CUES Inc., MPlus+ User Manual | CH905
www.cuesinc.com, | salesinfo@cuesinc.com
OPERATING THE SYSTEM
DPad CONTROLS DIAGRAM
P&T POPS UP A MENU CONTAIN THE CHOICES TOGGLE SONDE
ON/OFF, JOINT INSPECTION AND TOGGLE FREQUENCY HIGH/
LOW
CURVED RIGHT ARROW AT TOP OF DPAD ROTATE PAN & TILT
CAMERA CLOCKWISE
RIGHT ARROW AT RIGHT PAN THE PAN & TILT CAMERA TO THE
RIGHT
F+ FOCUS THE PAN & TILT CAMERA FAR
HOME HOME THE PAN & TILT CAMERA
F FOCUS THE PAN & TILT
CAMERA NEAR
CURVED RIGHT ARROW AT
BOTTOM OF DPAD ROTATE
PAN & TILT CAMERA COUNTER
CLOCKWISE
LEFT ARROW AT LEFT PAN
THE PAN & TILT CAMERA TO
THE LEFT
