CUES Inc., MPlus+ User Manual | CH905
www.cuesinc.com, | salesinfo@cuesinc.com
SET-UP & INSTALLATION
INSTALLING THE SELF UPRIGHT MINI
CAMERA AND CENTERING BALL -
STANDARD MPLUS, CONTINUED
Slide the bottom piece of the centering
ball onto the end of the CX- connector as
shown.
Secure the mini camera to the end of the
CX- connector as shown.
Place the top piece of the centering ball onto
the camera as shown.
Twist the top and bottom pieces of the
centering
ball together until secure.
