OPERATING THE SYSTEM
• PUSH ROD LENGTH
• XXX.X - NOTE: enter actual length to one decimal place using the Up Arrow and
Down Arrow keys to modify the value in the eld displayed. Use the Left Arrow and
Right Arrow keys to move within the eld. The value is changed upon exiting from
the eld by pressing ENTER or ESC.
• Prior to changing the cable’s length, all of the cable must be inside the basket/coiler
because the rmware assumes this is the case when computing the footage distance.
COILER SETUP
COILER TYPE
PUSH ROD LENGTH
COUNT DIRECTION
COILER SETUP
COUNT DIRECTION
UP
DOWN
COUNT DIRECTION
COILER TYPE
WARNING: ALL CABLE MUST
BE IN BEFORE PROCEEDING!
STANDARD BASKET
XL BASKET
AUXILIARY REEL
COILER TYPE
• The selection of ‘XL’ as the Coiler Type automatically selects large cable, internally.
• The combinations of large coiler with standard cable and standard coiler with large cable
are invalid and are currently not selectable.
• Changing the coiler type requires an internal reset of the distance calculation rmware,
which requires that all of the cable be retracted into the coiler for the distance to count
properly.
Count direction refers to whether the footage counts up or down when the cable is pulled out.
