22
Note: Be sure to power off the controller!
CWCCW
8
8
8
Disconnect the power plug.
Open the top cover of the controller.
The motor output wire is plugged into the
CW socket on the upper side of the circuit
board of controller by default, disconnect
the plug at CW, and insert it into the
empty CCW socket, the motor can be
reversed.
5.6 Motor Forward and Reverse Adjustment
The controller can realize the forward and reverse rotation of the motor by
adjusting the position of the output connector.
Position of CW
and CWW on
the circuit board
SDMC20-S
SDMC20_SMS-EN_2.01
Digital Single Phase Asynchronous Motor Controller
2023-11
10A250VAC
CCW
CW
