3
SensorⅡ
Preset
Ctrl Out
SensorⅠ
Photosensor
Speed Ctrl
A1
corresponding signal
GND
A2A
Input
A3+24V
B1GND
B2SAPset A
B3GND
B4SbPset B
C1oC
Output
C2+24V
D1GND
D2d
Input
D3+24V
E1GND
E2ERx
E3GND
E4Tx
F1+5V
F2
Input
F3RGND
Step 1: Remove the screws on the
four corners of the panel.
Step 2: Open the panel upwards,
the wiring port is in the back of the
panel.
10A250VAC
Saturated
Remote SpeedA SpeedB Stop
Variable Voltage Digital Controller
for
Vibratory Feeder
Frequency Hz
Voltage V
On Delay s
Soft Start s
Delay s
SDVC21-S
1.3 Wiring Ports Explanation
1.4 Nameplate Explanation
Product model
Serial Number
Date of manufacturer
Serial Number Description:
INS01-202111026db6-010067032BF
Specifications
Manufacturer
and address
{{
Input Voltage Range: 85～250VAC
Max Output Current: 5.0A
Max Output Power: 1100VA
Built in Starting Capacitor: 6uF/450VAC
For use at altitude 2000m or lower
Model SDMC20-S:
INS01-202111026db 6-010067032BF
Nanjing CUH Science & Technology Co.,Ltd
Add.:Building 2, Xueyan Tech Park, Tuscity, No.9 Zhineng Rd, Jiangning, Nanjing, China
Digital Single Phase Asynchronous
Motor Controller
SDMC20-S
SDMC20_SMS-EN_2.01
Digital Single Phase Asynchronous Motor Controller
2023-11
