35
24V
F1
F2
F3
E1
E2
E4
E3
+5V
+5V
10uF
249Ω
300Ω
10KΩ
10KΩ
10KΩ
6.8KΩ
100KΩ
A3/D3
A1/D1
A2/D2
7.2 Input and Output Circuit Diagrams
Switch Sensor Port A/D
Remote Speed Control Port F
Intelligent Photosensor Port E
Input
+5V
RGND
TX
RX
GND
GND
5V Output
Input
24V Output
GND
Auto sensor type recognition
SDMC20-S
SDMC20_SMS-EN_2.01
Digital Single Phase Asynchronous Motor Controller
2023-11
