6.1 Dimensions
Chapter Ⅵ Technical Specifications
SDMC20-S
SDMC20_SMS-EN_2.01
Digital Single Phase Asynchronous Motor Controller
2023-11
94.5
Dimensions (unit: mm)
Dimensions range
This tolerance table is applicable to all products in this series.
0~3
3~10
10~30
30~80
80~180
>180
tolerance
±0.05
±0.1
±0.15
±0.2
±0.3
±0.5
176.3±0.2
8
50
9*R2.5
4.5
8.3
190±0.2
13.69
37
36.3
182±0.2
51.8±0.1
R4
9
9
26.8
45.3±0.1
R2.1
1.8
53.6±0.1
9.5
