The GBE controller can operate several types of valves. Select from 4-CYCLE, 5-CYCLE or GBV.
For Softeners: For Filters:
CSM and Hi-Flo 50 are 5-CYCLE All are 4-CYCLE
Hi-Flo 22 and Hi-Flo 3e are 4-CYCLE
The type of resin changes how the GBE calculates capacity. Select from STANDARD or FINE.
Unless you change from the standard Cullex®, leave this at STANDARD.
Enter the water hardness (softeners only). This can be from an onsite test or from a water analysis.
Enter in the units shown on screen. For US-INCH, enter the hardness in grains per gallon (gpg).
This does NOT APPLY to commercial valves. Leave this set to A.
Enter the amount of iron present. This value can come from an onsite test or a water analysis.
Enter the value in ppm (mg/l).
This setting is either ABOVE or BELOW 40 PSI. If the pressure is below 40 psi, the brine
rinse time will be extended. This can be overridden by setting the brine rinse time manually by
going to 5) ADV SETUP, then 3) CYCLE TIMES.
Either standard sodium chloride (NACL) salt or potassium chloride (KCL) salt can be used. The
GBE needs to know which type is being used.
Select either SINGLE tank or PROGRESSIVE. Selecting PROGRESSIVE implies a multi-tank
system. Please refer to page 41 for details on setting up a multi-tank system.
THIS CAN BE IGNORED FOR COMMERCIAL APPLICATIONS.
Enter the volume of resin in the tank. This information can be found in the product’s installation
manual on the specifications page. Enter in the units shown. For US-INCH, enter the value in
cubic feet.
Select either US INCH or METRIC units. This will change the units when entering programming
values such as resin volume and flow rates. If you change this to METRIC, please review your
input for accuracy.
Set this to ON or OFF. This setting will tell the unit to rinse to drain at the time intervals and
duration set.
IF PRERINSE MODE IS SET TO ON
Select a prerinse time value from 1 to 240 hours. This tells the unit to rinse to drain if no flow is
detected for this duration.
Select the number of minutes the unit should rinse to drain when the NO FLOW duration has
passed.
This concludes the Advanced System Set-Up Menu. Continue to press the X key to return to the Main Menu.
dial-a
softness a
iron
present 0 ppm
line pressure
above 40 psi
salt type
nacl
multitank system
single
Customizing the Setup
Customizing the Setup 30
29 CULLIGAN GLOBAL ELECTRONIC CONTROLLER
units
us inch
prerinse mode
off
rinse if no flow
>for 24 hours
rinse for
>5 minutes
brine refill flow
0.45 gpm
resin volume
1.00 cu/ft
valve type
4-cycle
resin type
standard
hardness gpg
25
