46 Cummins INLINE™ 7 Data Link Adapter Installation and Setup Manual
Chapter 3 • Installing the Drivers and Setting Up the Device
If the Connection Indicator button is red (i.e., Not Connected), do one of the
following:
—For a wireless connection:
• In the De
vice list, make sure that the appropriate device is select-
ed, for example:
— INLINE7, Bluetooth
or
—INLINE7, WiFi
• In the Protocol list, make sur
e that the appropriate protocol is se-
lected, for example SAE J1939 Protocol.
• Check to ensure that the conn
ections between the INLINE™ 7
and the vehicle are secure (i.e., the Diagnostic Connector).
• Check to make certain that the Power
LED on the INLINE™ 7 is
illuminated.
—For a wired connection using a USB cable:
• In the De
vice list, make sure that the appropriate device is select-
ed, for example INLINE7, USB.
•In the Prot
ocol list, make sure the appropriate protocol is select-
ed, for example SAE J1939 Protocol.
• Check to ensure that the conn
ections between the INLINE™ 7
and the PC are secure (i.e., the USB cable).
• Check the connections between the INLINE™ 7 and the vehicle
(
i.e., the Diagnostic Connector).
• Check to make certain that the Power
LED on the INLINE™ 7 is
illuminated.
NOTE:
i For additional information, refer to “Connect the INLINE™ 7 to a Vehicle”
on page 30 of this manual.
6 Click
on the Component Info button.
