EJECT
TAILGATE LIFT
.06
SWEEP
PACK
22 GPM
1
2
3
4
7
6
5
10
11
12
9
.06
2700 PSI
2500 PSI
BACK PACK 1200 PSI AT 3 GPM
VELOCITY FUSE
2500 PSI
2500 PSI
8
13
14
REGULATOR - 1 TO 5 GPM
OPTIONAL FLOW
3200 PSI
RELIEF 2400 PSI AT 22 GPM
16
17
HAND VALVE
OPTIONAL CART TIPPER
CART DUMPER
OPTIONAL ROTARY
15
3200 PSI
ORIFICE, Ø 0.06
FILTER, RETURN 10 MICRON
TAILGATE LIFT CYLINDERS
EJECT CYLINDER
VALVE, MANUAL CONTROL BODY
PUMP
GATE VALVE
OIL RESERVOIR
1
SYM
3
2
5
4
7
6
9
8
NAME
SWEEP CYLINDER
10
PACK CYLINDER
ROTARY CART DUMPER (OPTION)
11
SYM
12
NAME
VALVE, MANUAL CONTROL TG
VALVE, FLOW REGULATOR
VALVE, MANUAL CART DUMPER
14
13
PRESSURE SWITCH, 2800 PSI
VALVE, DIVERTOR
VALVE, POPPET NORMALLY CLOSED
17
15
16
This drawing and the information thereon is the property of WAYNE ENGINEERING
CORPORATION. It may not be copied, duplicated, reproduced or used in any way to the
detriment of WAYNE ENGINEERING CORPORATION. This drawing is loaned to you and is
to be returned upon our request.
00-36245-05-MB
00-36245-05-MB
HYD SCHEMATIC, MANUAL VALVE
DAS
NONE
11/29/10
