SPECIFICATIONS | 29
Curbtender Hydraulic Fluid Recommendation
All Curbtender hydraulic systems are factory fi lled with a high quality anti-wear hydraulic fl uid
meeting an ISO 32 specifi cation. On units put into service where there are high ambient
temperatures or sustained high duty cycles, it may be desirable to change the fl uid to an ISO 46
specifi cation (higher viscosity). In colder climates or light duty cycles, an ISO 22 might be more
appropriate. The Interna-tional Standards Organization assigns specifi cation numbers so that a
consumer receives the same product from various suppliers. Refer to the previous chart for specifi
cations on diff erent ISO rated fl uids.
D
C
CA
F
G
CF
A
B
I
A: Overall Length
B: Height Above Chassis Frame
C: Body Width
D: Hopper Opening
E: Hopper Opening Height
F: Loading Sill Above Chassis Frame
G: Height of Tailgate Above Chassis Frame
CA: Cab to Axle
CF: Min. Usable Cab to End of Frame
Dynamic Hopper Capacity (cu. yd. / min)
Volumetric Hopper Capacity
Approximate Body Weight
Pack Cycle Time
158” 182” 200”
62”
83”
70”
45”
2”
110” (tailgate raised)
84” 108” 120”
116” 140” 152”
4.5 cu. yd.
1.0 cu. yd.
5520 lbs. 5920 lbs. 6020 lbs.
13 Seconds
6 cu. yd. 8 cu. yd. 10 cu. yd.
