16 | CURBTENDER, INC
BE CERTAIN NO ONE IS NEAR TAILGATE WHEN ACTIVATING
TAILGATE CONTROL. LOOKOUT FOR OVERHEAD OBJECTS.
UNLOADING CONTROLS
(THE 2 SPOOL VALVE IS LOCATED AT THE FORWARD, LEFT HAND SIDE OF THE BODY)
1) TAILGATE CONTROL LEVER- The tailgate lift cylinders are controlled by pushing in on the tail
gate control lever to lower the tailgate and pulling out to raise the tailgate.
2) EJECTOR PANEL CONTROL LEVER- The ejector panel extends into the body when the ejector
control lever is pushed inward and the ejector panel retracts to the front of the body when
the ejector control lever is pulled outward from the body. When transporting the vehicle,
move the ejector panel forward in the body
3) ENGINE ACCELERATOR SWITCH- The engine accelerator switch is installed on the 2 spool
valve bracket adjacent to the tailgate and ejector panel control levers. Actuation of this
electric switch will speed up the engine to provide adequate hydraulic pressure and ow for
raising the tailgate and ejector panel functions.
