4 — MONITOR MENU
MONITOR MENU
Through the monitor menu, the 13XX programmers provide access to real-time
data during vehicle operation. This information is helpful during diagnostics
and troubleshooting, and also during programmable parameter adjustment.
MONITOR MENU
ITEM VALUE DISPLAYED
MOTOR + BATTERY
Battery Voltage Voltage at KSI, in volts.
BSOC Battery state of charge.
Motor Speed Motor speed, in revolutions per minute.
Motor Voltage Motor voltage, in volts.
Motor Frequency Motor frequency, in hertz.
Slip Motor slip frequency, in hertz.
INPUTS
Throttle Input Throttle request: traction throttle.
Interlock Switch Interlock switch, on/off.
Forward Switch Forward switch, on/off.
Reverse Switch Reverse switch, on/off.
Mode Switch Mode switch, on/off.
Emergency Reverse Switch Emergency reverse switch, on/off.
Inhibit Input Inhibit input, on/off.
Speed Limit Speed limit request from pot or switch.
Horn Switch Horn switch on or off.
Hyd Throttle Input Throttle request: hydraulic throttle.
Lift Switch Lift switch, on/off.
Lower Switch Lower switch, on/off.
OUTPUTS
Aux Output 1 Aux 1 driver output.
Aux Output 2 Aux 2 driver output.
Prop Valve PWM Proportional valve PWM output.
Load Hold Valve Load hold valve driver output.
CONTROLLER
Temperature Controller internal temperature (MOSFETs).
Main Contactor Main contactor, open/closed.
Total Hourmeter Hours Total service hourmeter, in hours.
Drive Hourmeter Hours Drive service hourmeter, in hours.
Fault Position Additional fault information.
