APPENDIX C
SPECIFICATIONS
Table C-1 SPECIFICATIONS: 1230 CONTROLLER
Operating voltage range 16 to 32 V
Nominal input voltage 24 V
PWM operating frequency 16 kHz
Electrical isolation to heatsink 500 V ac (minimum)
KSI input current (no contactors engaged) 90 mA without programmer or speed encoder
170 mA with programmer and SKF speed encoder
Logic input voltage >7.5 V High; <1 V Low
Logic input current 10 mA (nominal)
Nominal output line-to-line voltage (rms) 15 V
Max. output frequency >200 Hz
Operating ambient temp. range -40°C to 50°C (-40°F to 122°F)
Storage ambient temperature range -40°C to 85°C (-40°F to 185°F)
MOSFET overtemperature cutback
linear cutback starts at 100°C (212°F); complete cutoff at 110°C (230°F)
MOSFET undertemperature cutback approx. 50% motor current at -25°C (-13°F); complete cutoff at -40°C (-40°F)
Package environmental rating IP53
Weight 1.1 kg (2.2 lbs)
Dimensions (L
×W×H) 164 × 146 × 57 mm (6.5" × 5.8" × 2.3")
Regulatory compliance EMC emissions: EN50081-2/08.93
EMC immunity: EN50082-2: 1995
Safety, uncontrolled runaway: EN1175
UL Recognized Component; meets UL583 dielectric test.
APPENDIX C: SPECIFICATIONS
C-1
NOMINAL
MODEL-SPECIFIC FEATURES
BATTERY 2 MIN 1 HOUR INTERNAL 1312 TWO
MODEL VOLTAGE RATING
*
RATING
*
MAIN MULTIPLEXER AUXILIARY CAN
NUMBER (volts) (amps) (amps) CONTACTOR INTERFACE OUTPUTS INTERFACE
1230-2001 24 60 30 ✓ ✓ ✓ —
-2002
24 60 30 — — — —
1230-2101 24 90 40
✓ ✓ ✓ —
-2102 24 90 40 — — — —
1230-2201 24 120 50
✓ ✓ ✓ —
-2202 24 120 50 — — — —
1230-2301 24 150 60 — ✓ ✓ —
-2302 24 150 60 — — — —
1230-2401 24 200 80 — ✓ ✓ —
-2402 24 200 80 — — — —
-2403 24 200 80 — — ✓ ✓
*
Controller mounted to 250 × 250 × 5 mm aluminum plate,
with continuous 5 kph airflow perpendicular to back of plate,
and 25°C ambient temperature.
