Curtis 1212 Manual
3 — PROGRAMMABLE PARAMETERS: Throttle Parameters
THROTTLE MENU, cont’d
ALLOWABLE
PARAMETER RANGE DESCRIPTION
Throttle Map 20–80 % The throttle map parameter adjusts the static throttle map. The parameter
setting corresponds to the throttle command at half throttle, as shown in
Figure 7.
A setting of 50% provides linear response. Values below 50% reduce
the throttle command at low throttle positions, providing enhanced slow
speed maneuverability. Values above 50% give the vehicle a faster, more
responsive feel at low throttle positions.
Tremor Suppression 0–100 % This parameter can be used to limit the controller’s response to sharp
throttle movements, such as movements resulting from hand tremors.
Larger values will provide a steadier ride, but they also result in more
sluggish response to throttle request. There is thus a trade-off between
crispness of response (low Tremor Suppression settings) and steady
speed in the presence of tremors (high settings).
Fig. 7 Effect of throttle
adjustment parameters.
These four parameters
determine the controller’s
response to throttle position,
in forward and reverse.
Here,
Deadband = 10%
Throttle Max = 90%
Creep = 0%.
