Curtis 1212 Manual
Table 2-0 STATUS LED FAULT CODES, TYPE 0
TYPE 0 LED CODES FAULT
LED off no power or defective controller
solid on controller powered up; no faults
1,1
¤ ¤ THERMAL FAULT
1,2 ¤ ¤¤ THROTTLE FAULT
1,3 ¤ ¤¤¤ SPEED POT FAULT
1,4 ¤ ¤¤¤¤ UNDERVOLTAGE FAULT
1,5 ¤ ¤¤¤¤¤ OVERVOLTAGE FAULT
2,1 ¤¤ ¤ MAIN OFF FAULT
2,2 ¤¤ ¤¤ (not used)
2,3
¤¤ ¤¤¤ MAIN FAULT ❊
2,4 ¤¤ ¤¤¤¤ MAIN ON FAULT
2,5 ¤¤ ¤¤¤¤¤ (not used)
3,1
¤¤¤ ¤ WIRING FAULT ❊
3,2 ¤¤¤ ¤¤ BRAKE ON FAULT
3,3 ¤¤¤ ¤¤¤ PRECHARGE FAULT ❊
3,4 ¤¤¤ ¤¤¤¤ BRAKE OFF FAULT
3,5 ¤¤¤ ¤¤¤¤¤ HPD FAULT
4,1 ¤¤¤¤ ¤ CURRENT SENSE FAULT ❊
4,2 ¤¤¤¤ ¤¤ HARDWARE FAILSAFE ❊
4,3 ¤¤¤¤ ¤¤¤ EE CHECKSUM FAULT †
4,4 ¤¤¤¤ ¤¤¤¤ (not used)
4,5
¤¤¤¤ ¤¤¤¤¤ BATTERY DISCONNECT FAULT ❊
7 — DIAGNOSTICS & TROUBLESHOOTING
❊ = Must cycle keyswitch to clear.
† = Must use programmer to clear, as follows: select Program menu,
alter data value of any parameter, cycle keyswitch.
Type 0 Fault Codes
When Fault Code Type parameter is set to 0, the status LED uses a 2-digit
code. For example, code “1,4”—undervoltage—appears as:
¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤
( 1 , 4 ) ( 1 , 4 ) ( 1 , 4 )
The Type 0 fault codes are listed in Table 2-0.
