Curtiss-Wright DTS1+ CSfC - Page 85

User Guide DDOC0199-000-A9
1-Slot Data Transport System (CSfC) 10 - 2 Troubleshooting
© 2024 Curtiss-Wright Defense Solutions Revision 0.0
10.3 Encryptor Error Codes
NOTE
If problems persist, contact Curtiss-Wright Defense Solutions Customer Support. Refer to
paragraph 1.6 Technical Support for contact information.
Refer to Table 10.3 for fault information.RMC module
Table 10.2 RMC Module LED Fault Indications
Symptoms/Condition Meaning Investigative/Remedial Action
RMC module red Fault LED on. Self-test failed
1. Run ibit CLI command. If the problem can
be associated with the RMC module, run
mbit CLI command.
2. Reseat RMC module and cycle power.
Cannot store data. RMC module may be full. Run rmcfree CLI command.
Table 10.3 Encryptor Error Codes
Symptoms/Condition Meaning Investigative/Remedial Action
0x0103 AES Memory allocation error
0x0109 AES KAT (known answer test) failed
0x0203 KEY_WRAP Memory allocation error
0x0209 KEY_WRAP KAT (known answer test) failed
0x0210 KEY_WRAP Initialization vector error
0x0303 SHA Memory allocation error
0x0309 SHA KAT (known answer test) failed
0x0403 HMAC Memory allocation error
0x0409 HMAC KAT (known answer test) failed
0x0503 DRBG Memory allocation error
0x0509 DRBG KAT (known answer test) failed
0x0603 RNG Memory allocation error
0x0609 RNG KAT (known answer test) or continual test failed
0x0720 encryptor 3.3Vpower supply error
0x0730 encryptor 2.5Vpower supply error
0x0740 encryptor 1.8Vpower supply error
0x0709 encryptor KAT (known answer test) failed
0x0810 I2C Interrupt handler error
0x0901 SATA_P_CTRL Initialization error
0x0904 SATA_P_CTRL Write error
0x0905 SATA_P_CTRL Read error
0x0A10 ENCRYPTION Chip_A BIST error
0x0A20 ENCRYPTION Chip_B BIST error
0x0A30 ENCRYPTION Chip_C BIST error
0x0A40 ENCRYPTION Chip_D BIST error
0x0A50 ENCRYPTION Chip_A POST error
