3. PRINTER FUNCTIONS3. PRINTER FUNCTIONS
KPM216H
213-
yL + yH × 256 specifies the number of lines to print.
[Notes] • If (xL + (xH × 256)) > dhmax the printer does not execute the command.
• If ( xL + ( xH × 256 ) + yL +( yH × 256 ))> dhmax the printer prints only
dhmax - xL + ( xH × 256 ) +1 dotline.
• After the print of the logo from RAM (n= 0 ), the graphic page is deleted. If
the user wants to print again or save the logo into the flash, the user must
retransmit or reload it with the command ESC ³.
• To print a text string before the logo, send a LF, because the logo printing
buffer and the characters buffer is the same.
• If don’t modify the logo stored into flash bank, use this command with n =
1.
[Default]
[Reference] ESC ³, ESC ², ESC ¦
[Example] To print from ram bank dotline 100 to dotline 299, send:
1BH FAH 00H 00H 64H 00H C7H
)ECAFRETNILAIRESHTIWYLNO(HnLn}{CSE
[Name] Transmit graphic page to communication port
[Format] ASCII ESC { } nL nH
Hex 1B FB nL nH
Decimal 27 251 nL nH
[Description] Transmits [nL + (nH × 256)] word of graphic page used at the moment to
the communication port.
[Default]
[Reference] ESC ³, ESC ², ESC ¦
[Example]
n}{CSE
[Name] Transfer flash bank into graphic page
[Format] ASCII ESC { } n
Hex 1B FC n
Decimal 27 252 n
[Range] n = 1
[Description] Transfers flash bank into graphic page used at the moment
n selects the flash bank as follows:
nnoitcnuF
1marotni1ogolknabhsalfsrefsnarT
[Notes] • Don’t lose the logo holded into the graphic page don’t send, after this
command, other control characters to the printer which operate on the
printing buffer (LF, FF) as the logo printing buffer and the characters is the
same. The only commands which don’t cancel the logo stored in the
