NOTCH DISTANCE “Notch Distance” is the minimum distance (in mm) between the upper edge of ticket and
the black mark.
The numeric value of the distance is made up with the following four parameters for the
setting of three digits (two for the integer part of the number and one for the decimal part)
and of the sign:
NOTCH DISTANCE [mm x 10]
Setting the digit for tens:
0
D
2 4 6 8
1 3 5 7 9
NOTCH DISTANCE [mm x 1]
Setting the digit for units:
0
D
2 4 6 8
1 3 5 7 9
NOTES:
For example, to set the black mark distance to 15 mm, modify the parameters as follows:
Notch Distance [mm x 10] = 1
Notch Distance [mm x 1] = 5
If the “Notch Alignment” parameter is disabled, the parameters for the “Notch Distance” are not printed.
In Setup mode, it is possible to set the black mark distance using a values range from 0mm to 39mm. The
maximum distance accepted is 32mm, so even if values from 33mm to 39mm are inserted, the distance
remains 32mm.
CURRENT Setting of the current consumption:
Low
High
Normal
D
LEFT MARGIN OFFSET
Reserved
RIGHT SPACER Reserved
FONT TYPE Setting of the Font Type:
International
D
= Enables the use of font tables to 256 characters
Chinese GB18030 = Enables the use of the Chinese extended font GB18030-2000
Korean PC949 = Enables the use of the Korean extended font PC949
NOTE: When the Chinese and Korean font is enabled, the selection of the character code table is suspended
(parameter “CODE TABLE”). When the Chinese and Korean fonts is disabled, it returns the character code
table previously in use (parameter “CODE TABLE”).
47
