14
PRINTER DESCRIPTION
Descrizione stampante
Drucker beschreibung
1. Opening levers of paper compartment
2. Cover for paper compartment
3. Near paper end sensor
4. Blade for manual tear-off
5. Paper presence sensor
6. Sensor of cover open
7. Status led
8. FEED key
9. ON/OFF key
10. Ethernet connector
11. Drawer connector
12. Power supply connector
1. Leve apertura vano carta
2. Coperchio vano carta
3. Sensore quasi fi ne carta
4. Strapperina manuale
5. Sensore presenza carta
6. Sensore coperchio vano carta aperto
7. LED di stato
8. Tasto FEED
9. Tasto ON/OFF
10. Connettore ETHERNET
11. Connettore cassetto
12. Connettore alimentazione
1. Öffnungshebel Papierfach
2. Deckel für Papier-Fach
3. Sensor der Nähe von Papier Ende
4. Klinge für die manuelle Abreißen
5. Papiermangelsensors
6. Papier Deckelöffnungssensor
7. STATUS-LED
8. FEED Taste
9. On/Off Taste
10. Ethernet-Anschluss
11. Schublade Anschluss
12. Netzteil-Anschluss
1
6
3
4
5
7
8
9
10 11 12
2
