WIRELESS ACCESS POINT: DESCRIPTION (cod.972GU010000301)
Access point wireless: Descrizione (cod.972GU010000301)
Wireless Access Point: Beschreibung (cod.972GU010000301)
1. Power supply for access point
2. Access point
3. Led for Ethernet transmission
4. Led for Wireless transmission
5. Led for AP active
6. Default button
7. 10BaseT RJ45 LAN/WAN port
8. Jack power supply connector
NOTE:
Do not connect this device to the printer!
1. Alimentatore per access point
2. Access point
3. Led per la trasmissione Ethernet
4. Led per la trasmissione Wireless
5. Led per l’AP attivo
6. Pulsante Default
7. Connettore RJ45 10BaseT LAN/WAN
8. Connettore jack per l’alimentazione
NOTA:
Non collegare questo dispositivo alla stampante.
1. Access Point Netzgerät
2. Access Point
3. Led für Ethernet-Übertragung
4. Led für Wireless-Übertragung
5. Led für aktive AP
6. Default Taste
7. RJ45 10BaseT LAN/WAN Steckverbinder
8. Stromanschluss
HINWEIS:
Dieses Gerät nicht an den Drucker anschließen!
Default LAN
DC IN 5V
ANT.
rear view
1
2
3
4
5
6
7
8
