Custom Engineering KUBE II ETH - CONNECTIONS; Connection Diagram

Custom Engineering KUBE II ETH
68 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
KUBE II-ETH power supply
Power Supply cable
RJ11 VIn 24Vdc
RJ45
PCHUB
ETHERNET UTP
standard cable (pin-to-pin)
ETHERNET
CrossOver standard cable
DRAWER
(OPTIONAL)
Cable supplied with drawers
INSTALLATION
15
CONNECTIONS
Collegamenti
Anschlüsse
