Install accessory tray bottom
1. Install the grommet to the frame.
QtyDescription
1Grommet1
1Frame2
2. Install the accessory tray bottom to the accessory tray base with three screws using a Phillips
screwdriver.
QtyDescription
1Accessory tray bottom1
1Accessory tray base2
3Screws3
Remove left and right handle assembly
The left and right handle assemblies are shipped in rotated positions. The handle assemblies must be
removed and rotated 180 degrees for proper setup and assembly.
Page 18 of 82
Cybex 525AT Arc Trainer Part Number 5525-4 F
