3. Align the top step to be centered between the hood cover support and end cap.
The gaps should be equal.
Qty.DescriptionItem
1Motor cover support1
1Gaps2
1Top step3
1End cap4
Do not use power toolsThe deck holes will strip out if over tightened.
4. Tighten the five screws to 28 in-lbs (3.16 Nm) using a torque screwdriver.
5. Install the five screw covers to the top step.
6. Repeat steps for the left top step.
Complete Installation
Operate the unit at all levels to verify proper operation.
Top Steps
Tools Required:
Phillips screwdriver
Flat head screwdriver
Disconnect power source
1. Toggle the on/off (I/O) power switch to the off (O) position. The on/off (I/O) power switch is located
under the front end of the unit, or on the front right side panel.
2. Unplug the treadmill from the power outlet.
Shock and electrocution hazard.
Unplug unit and let sit 10 minutes before cleaning or performing
maintenance.
Electrical charge can remain in unit after unplugging.
Keep water and liquids away from electrical parts.
