CYBEX 525T Service Manual

2. Install the bolt, washer, bushing and rear roller nut for each side of the roller into position.
Qty.DescriptionItem
1Rear roller nut1
1Bushing2
1Washer3
1Bolt4
1Rear roller5
3. Tighten the two rear roller bolts using a 3/4” Socket wrench.
Tighten each bolt evenly, making sure not to tighten either bolt too many turns before moving to the
other bolt.
4. Continue to tighten bolts until the front roller is all the way back in the tensioning slots.
5. Tighten the front roller bolts using a 9/16” Socket wrench.
6. Tighten the rear roller bolts to 100 in-lbs (11.3 Nm) using a torque wrench.
Install top steps
1. Install the five screws and five screw cover bases securing the right top step using a Phillips
screwdriver.
Do not tighten screws at this time.
Qty.DescriptionItem
5Screw cover1
5Screw2
5Screw cover base3
1Top step, right4
2. Install the five screws and five screw cover bases securing the left top step using a Phillips
screwdriver.
Page 125 of 199
