CYBEX 525T Service Manual

2. Slide the drive belt around the front roller before attaching the front roller.
Qty.DescriptionItem
1Front roller1
1Drive belt2
1Tensioning slot3
1Mounting bolt4
3. Install the two roller bolts that fasten the front roller to the frame.
Do not tighten the bolts at this time.
Ensure that the drive belt is aligned properly in the grooves on the drive motor pulley and front roller
pulley. The drive belt should be positioned in the inner most groove of the drive motor pulley.
Qty.DescriptionItem
1Front Roller Pulley1
1Drive Belt2
1Drive Motor Pulley3
Install rear roller
1. Slide the rear roller into the running belt.
Page 124 of 199
