CYBEX 525T Service Manual

6.
Press the ENTER key to scroll through options.
Diagnostics menu:
Displays Drive software version and MCC board software version.Test homeT1
Press Quick Start key to start. A quick LED text begins with lighting the follow-
ing for three seconds each. Bar Graph Matrix (BGM) LED's and heart in red,
center numerics and heart in green, membrane LED’s and heart in blue.
LED test
Press Workouts key to start. Test each key by pressing once. Each key press
is recognized with a beep, center numeric displays assigned number per key.
Press Stop key once to test, hold for two seconds to exit key test.
Key test
Displays Set frequency, Actual frequency and number of foot falls. Foot falls
is the count of steps taken on the running belt. Incline and speed keys are
active.
Drive frequencyT2
Displays input line current and output drive current. Quick Start key is active
to start the running belt. Incline and speed keys are active.
AmpsT3
Displays drive motor output voltage and bus voltage. Quick Start key is active
to start the running belt. Incline and speed keys are active.
VoltsT4
Displays drive motor temperature in degrees Celsius. Quick Start key is active
to start the running belt. Incline and speed keys are active.
TemperatureT5
7.
Press the STOP key to return to Dormant Mode. If drive motor was running press the STOP key
again.
Error Codes 525T Treadmill
Error codes notify user of a problem condition and are displayed on the console. Error codes can also
help to indicate the part of the unit most likely to be causing the problem.
Known conditions that will generate errors:
•
Shutting of the power while the belt is moving (Error 3, 5, 95 and 99 possible)
• Cycling power too quickly (SVC-95 with no error stored)
•
Setting the line frequency to not match the input (Error 141, 140)
•
Display watchdog resets cause a pair of codes, 9 and 99, to appear in sequence
NOTE: Errors < 90 are console generated. The console software has determined an error condition
exists that either doesn’t involve the drive or hasn’t caused the drive to malfunction. All errors
generated by or reported by the motor controller are 90 or greater.
Access error log
1. Press the STOP key several times.
2.
Press and the hold the Display option and DOWN keys for 3 seconds.
Page 56 of 199
