Install end caps
1. Install the two screws securing the right end cap using a Phillips screwdriver.
Qty.DescriptionItem
1Right end cap1
2Screws2
2. Repeat step for left end cap.
3. Align the top step to be centered between the hood cover support and end cap.
The gaps should be equal.
Qty.DescriptionItem
1Motor cover support1
1Gaps2
1Top step3
1End cap4
Do not use power toolsThe deck holes will strip out if over tightened.
4. Tighten the five screws to 28 in-lbs (3.16 Nm) using a torque screwdriver.
5. Install the five screw covers to the top step.
6. Repeat steps for the left top step.
Center and tension the running belt
1. Plug the power cord into the power outlet.
2. Turn the main power switch to the on (I) position.
3. Tap the Quick Start icon.
Page 118 of 199
Cybex 525T Treadmill Part Number
