3. Align the top step to be centered between the hood cover support and end cap.
The gaps should be equal.
Qty.DescriptionItem
1Motor cover support1
1Gaps2
1Top step3
1End cap4
Do not use power toolsThe deck holes will strip out if over tightened.
4. Tighten the five screws to 28 in-lbs (3.16 Nm) using a torque screwdriver.
5. Install the five screw covers to the top step.
6. Repeat steps for the left top step.
Center and tension the running belt
1. Plug the power cord into the power outlet.
2. Turn the main power switch to the on (I) position.
3. Tap the Quick Start icon.
4. Press the Speed + key to bring the speed up to 5 mph (8 kph). Allow the treadmill to run for a minute.
The lateral position of the running belt is correctly centered when the Cybex logo is centered between
the inside edges of the two belt tracking slots. If the Cybex logo is not centered between the belt
tracking slots, center the running belt with the following procedure.
5. Observe the Cybex logo position relative to the belt tracking slots with the treadmill running at 5 mph
(8 kph).
Qty.DescriptionItem
1Cybex logo1
1Running belt2
4Belt tracking slot3
While centering the running belt choose one bolt to adjust. Do not adjust both bolts.
Page 136 of 199
Cybex 525T Treadmill Part Number
