Install motor cover
1. Place the motor cover into position vertically by aligning the two tabs and four plastic connectors.
Two plastic connectors are mounted in the front cover and two in the motor cover. If motor cover
top does not fit properly, loosen the side screws as needed.
Qty.DescriptionItem
1Motor Cover1
1Front Cover2
2Screws3
4Plastic Connectors4
2. Tighten the two front cover screws using a Phillips screwdriver.
Be sure the screws are securing the motor cover's tabs.
Center and tension the running belt
1. Plug the power cord into the power outlet.
2. Turn the main power switch to the on (I) position.
3. Tap the Quick Start icon.
4. Press the Speed + key to bring the speed up to 5 mph (8 kph). Allow the treadmill to run for a minute.
The lateral position of the running belt is correctly centered when the Cybex logo is centered between
the inside edges of the two belt tracking slots. If the Cybex logo is not centered between the belt
tracking slots, center the running belt with the following procedure.
5. Observe the Cybex logo position relative to the belt tracking slots with the treadmill running at 5 mph
(8 kph).
Qty.DescriptionItem
1Cybex logo1
1Running belt2
4Belt tracking slot3
While centering the running belt choose one bolt to adjust. Do not adjust both bolts.
Page 158 of 199
Cybex 525T Treadmill Part Number
