Cybex Owner’s Manual
WARNING: Heavy equipment:
• At least two people must lift, move or assemble unit.
• Use safe lifting methods.
Lift and move the unit
Take note of doorway widths in facility before assembly. The base is 32.5” (83 cm) wide. With uprights
installed the width is 35.6” (90.5 cm).
At least two people should lift and move the treadmill to a level location where you intend to leave it.
Use proper lifting methods.
Remove shield
1. Loosen but do not remove the two front cover screws securing the motor cover using a Phillips
screwdriver.
3
1
2
Item Description
1 Motor cover
2 Front cover
3 Screws (2)
2. Remove motor cover by lifting vertically.
3. Loosen but do not remove the seven screws securing the sheild to the base using a Phillips
screwdriver.
2
3
1
Item Description
1 Base
2 Screws (7)
3 Shield
4. Remove shield by sliding sideways and then vertically off of base.
