Cybex Owner’s Manual
1. Loosen but do not remove the two front cover screws securing the motor cover using a Phillips
screwdriver.
3
1
2
Description
1 Motor cover
2 Front cover
3 Screws (2)
2. Remove motor cover by lifting vertically.
3. Loosen but do not remove the seven screws securing the sheild to the base using a Phillips
screwdriver.
2
3
1
Description
1 Base
2 Screws (7)
3 Shield
4. Remove shield by sliding sideways and then vertically off of base.
5. Use a vacuum attachment or hand vacuum to clean the exposed elevation assembly, drive
motor, lower electronics and the surrounding areas.
